List of items for which BHEL seeks interest of Local suppliers

BHEL Unit Item Description Projected Procurement Value for next 5 years (Rs Cr.)
2025-26 2026-27 2027-28 2028-29 2029-30
Castings and Forgings
HEEP, Haridwar Rotor Forging   Details 48 40 35 40 45
HEEP, Haridwar FORGING FOR WINDING SUPPORT RING (DE & NDE)   Details 0.52 0.52 .52 0.75 0.75
HEEP, Haridwar IP OUTER CASING (UPPER HALF & LOWER HALF)-NODULAR GRADE   Details 32 25 20 30 30
HEEP, Haridwar FORGING FOR ARMATURE CLAMPING   Details .246 .246 .246 0.30 0.50
HEEP, Haridwar RETAINING RING FORGING   Details 17 30 30 30 30
HEEP, Haridwar Forging for IP shaft   Details 38 55 130 125 65
HEEP, Haridwar INTERMEDIATE RING FOTGING AND FORGING FOR HALF RING   Details 0.91 0.91 .91 1.0 1.20
HEEP, Haridwar LP rotor shaft forging   Details 60 97 205 190 105
HEEP, Haridwar Forging for HP Rotor   Details 30 45 100 90 50
HEP, Bhopal Retaining ring (NF forging), MOC-CuNiaAl forging)   Details 1 1 1 1 1
HEP, Bhopal Hydro generator shaft forging   Details 14 18 18 18 18
HEP, Bhopal HEEP, Haridwar HPEP Hyderabad Retaining ring forging   Details 3.00 3.00 3.00 3.00 3.00
HPEP, Hyderabad Rotor Forging (For Generator above 100 MW)   Details 16 16 16 18 18
HPEP, Hyderabad Rotor Forging (For Generator above 100 MW)   Details 16 16 16 18 18
HPEP, Hyderabad Casing Forgings for Compressors   Details 0.80 1.00 1.04 1.04 2.08
HPEP, Hyderabad Casing Forgings for Compressors   Details 0.80 1.00 1.04 1.04 2.08
HPEP, Hyderabad Retaining Ring Forging for Turbo-generator   Details 18 18.6 18.6 15.0 15.0
HPEP, Hyderabad Retaining Ring Forging for Turbo-generator   Details 18 18.6 18.6 15.0 15.0
HPEP, Hyderabad Rotor Wedge   Details 3.80 3.90 3.90 3.90 5.00
HPEP, Hyderabad Rotor Wedge   Details 3.80 3.90 3.90 3.90 5.00
Components - Mechanical
BAP, Ranipet Gas to Gas Heater for FGD   Details 8.00 8.00 8.00 8.00 8.00
BAP, Ranipet Spring supported shaft seal   Details 0.20 0.20 0.20 0.20 0.20
BAP, Ranipet Cold end Basketed Enameled heating elements for Air Pre-Heaters   Details 3.6 6.4 6.4 6.4 6.4
BAP, Ranipet Cold end Basketed enamelled heating element for APH   Details 1.00 1.00 1.00 1.00 1.00
BAP, Ranipet High Pressure Soot Blower for Air Preheater   Details 2.00 2.00 2.00 2.00 2.00
BAP, Ranipet Spherical Roller Thrust Bearing for Air Pre-Heaters 294/850 and 294/900   Details 19.2 10.77 9.88 8.98 9.88
BAP, Ranipet Hydraulic Actuating devices   Details 2.00 2.00 2.00 2.00 2.00
BAP, Ranipet Pillow Block   Details 1.00 1.00 1.00 1.00 1.00
BAP, Ranipet Shaft Bush   Details 0.10 0.10 0.10 0.10 0.10
BAP, Ranipet Self vulcanizing Bromo Butyl Rubber lining for absorber tanks of FGD   Details 10.00 10.00 10.00 10.00 10.00
EDN, Bangalore LEAKPROOF QUICK COUPLING   Details 2.51 2.51 2.51 2.51 3.00
HEEP, Haridwar PISTON RING AND SPRING RING   Details 3.34 3.34 3.34 5.00 5.00
HEEP, Haridwar Stud Heating and Measuring Device   Details 3.5 1.5 1.5 1.5 1.75
HEEP, Haridwar Hydraulic Hose Line   Details .65 .65 .65 1.0 1.0
HEEP, Haridwar Stationary Blade Ring   Details 7.8 7.8 7.8 10.0 10.0
HEEP, Haridwar Cold Rolled Sealing Profile   Details 3.36 3.36 3.36 5.00 5.00
HEEP, Haridwar Hydraulic Motor Assembly   Details 3 2.5 2.5 2.5 3.0
HEEP, Haridwar Blade Vibration Monitoring System   Details 10 10 10 12 12
HEP, Bhopal AXIAL SHAFT SEAL   Details 12.00 12 12 12 12
HEP, Bhopal 6FXA Motor Bearing set (1) M/s SKF/Germany, Austria DE:NU224ECPC4.VA301, NDE: NJ219ECP.C4.VA309+HJ219 EC.VA301 (2)M/s Schaeffler Technologies AG & Co. KG /Germany, Romania, Italy (Brand name- FAG) DE: NU224E.M1.C4.F1 NDE:NJ219-E-XL-TVP2- F1-J20A C4+HJ219-E-F1   Details 0.44 0.44 0.44 0.44 0.44
HEP, Bhopal Anti Friction Bearings   Details 9.60 9.60 9.60 9.60 10
HEP, Bhopal contact assy   Details 0.08 0.08 0.08 .08 0.08
HEP, Bhopal Plug socket assy   Details 0.05 0.05 0.05 0.05 0.05
HEP, Bhopal Bearings for Alternator (Ball bearing type 6318M/C4 )   Details 0.08 0.08 0.08 0.08 0.08
HEP, Bhopal Bearings NH 318 ECMRA/C4 VA3091 & NU 324 ECMRA/C4 VA301 for Traction Motor IM3302/IM3602   Details 6.68 6.68 6.68 6.68 6.68
HEP, Bhopal NU 2236 ECMRD/C4 VA301 & NJ 320E-CM/P64VA3091+ HJ320EC.VA301 for Traction Motor 6 FRA 6068 Bearing   Details 16.80 16.80 16.80 16.80 16.80
HEP, Bhopal Traction Motor Bearings   Details 17.80 17.80 17.80 17.80 20
HEP, Bhopal Ball bearing type 6318M/C4 (SKF nomenclature)   Details 13.64 13.64 13.64 13.64 15
HERP, Varanasi STUD HEATING & MEASURING DEVICE (HW-618.00) -- AS PER DRG. 11201556600 REV.00 (HWR MATL. CODE-W90312015020)   Details 0.37 0.37 0.37 0.37 0.37
HERP, Varanasi STAINLESS STEEL STRIP SIZE 8X1 MM (HW-165.66.2) -- AS PER SPEC:HW10779 REV.02 LENGTH:445 M; WEIGHT:28 KG (HWR. MATL. CODE - W97311202140)   Details 0.22 0.22 0.22 0.22 0.22
HERP, Varanasi WRENCH FOR BALANCING WEIGHT   Details 0.175 0.175 0.175 0.175 0.175
HERP, Varanasi STUD HEATING & MEASURING DEVICE   Details 3.46 1.38 1.38 1.38 1.38
HERP, Varanasi STUD HEATING & MEASURING DEVICE   Details 3.46 1.38 1.38 1.38 1.38
HERP, Varanasi HEATING AND MEASURING DEVICES (HW-292.94)-- AS PER STD. ST38007 REV.03(HWR MATL.CODE - W97371905024)   Details 0.14 0.14 0.14 0.14 0.14
HPBP, Trichy Rotary coal feeder: Capable of operating continuously at a defined speed to feed the solid particles into high pressure gasifier. The gasifier will be operating at a pressure of 31 Kg/cm2 abs and the feeder has to operate continuously without leakage to maintain the coal flow into the system   Details 0 2.6 0 2.6 0
HPBP, Trichy Rotary ash extractor: Capable of operating continuously at a defined speed to extract solid particles from gasifier operating at high pressure. The gasifier will be operating at a pressure of 31 Kg/cm2 abs and the extractor has to operate continuously without leakage to maintain the ash level in the system.   Details 0 1.3 0 1.3 0
HPBP, Trichy Hemi spherical dishes ends   Details 10 10 12 10 10
HPBP, Trichy Fittings Gr F92   Details 40 40 48 40 40
HPBP, Trichy Forged Finned Elbows   Details 10 10 12 10 10
HPBP, Trichy Water cooled screw cooler: It is used to extract ash from high pressure gasifier in a controlled rate. The screw cooler for high pressure application is water jacketed to cool the in syngas atmosphere. The screw cooler should withstand high pressure and should not allow any leakage of syngas. The high temperature (1000 deg C) and high pressure (32.6 Kg/cm2 abs), water cooled screw cooler is intended to cool & convey fly / bottom ash from gasifier bottom outlet to ash receiver.   Details 0 78 0 78 0
HPEP, Hyderabad Journal Bearings for Compressors   Details 0.80 0.80 0.80 1.00 1.00
HPEP, Hyderabad Stainless Steel Flats for Steam Turbine Blades   Details 12.92 14.06 15.20 16.72 15.20
HPEP, Hyderabad Stainless Steel Flats for Steam Turbine Blades   Details 12.92 14.06 15.20 16.72 15.20
HPEP, Hyderabad Journal Bearings for Compressors   Details 0.80 0.80 0.80 1.00 1.00
HPEP, Hyderabad Thrust Bearings for Compressors   Details 0.30 0.30 0.30 0.30 0.50
HPEP, Hyderabad Thrust Bearings for Compressors   Details 0.30 0.30 0.30 0.30 0.50
HPEP, Hyderabad Tilting Pad Thrust bearings for Steam Turbines   Details 0.50 0.50 0.50 0.75 0.75
HPEP, Hyderabad Tilting Pad Thrust bearings for Steam Turbines   Details 0.50 0.50 0.50 0.75 0.75
HPEP, Hyderabad Rotor Forgings>30 Tons for Steam Turbines   Details 2.50 3 6 3 3
HPEP, Hyderabad Rotor Forgings>30 Tons for Steam Turbines   Details 2.50 3 6 3 3
HPEP, Hyderabad Brush Seals   Details 0.15 0.15 0.15 0.20 0.20
HPEP, Hyderabad Brush Seals   Details 0.15 0.15 0.15 0.20 0.20
HPEP, Hyderabad Turbine Blade profiles   Details 1.00 1.00 1.00 1.00 1.25
HPEP, Hyderabad Turbine Blade profiles   Details 1.00 1.00 1.00 1.00 1.25
HPEP, Hyderabad Tilting Pad Journal bearings for Steam Turbines   Details 0.50 0.50 0.50 0.75 0.75
HPEP, Hyderabad Tilting Pad Journal bearings for Steam Turbines   Details 0.50 0.50 0.50 0.75 0.75
HPEP, Hyderabad Dry gas seal   Details 1.76 1.76 1.76 1.76 1.76
HPEP, Hyderabad Dry gas seal   Details 1.76 1.76 1.76 1.76 1.76
HPEP, Hyderabad Axial Compressor (Axial Blower or Turbo Blower)   Details 120 0 180 120 180
HPEP, Hyderabad Axial Compressor (Axial Blower or Turbo Blower)   Details 120 0 180 120 180
HPEP, Hyderabad Stainless Steel Profile Bars for Steam Turbine Blades   Details 4.8 4.8 4.8 4.8 4.8
HPEP, Hyderabad Stainless Steel Profile Bars for Steam Turbine Blades   Details 4.8 4.8 4.8 4.8 4.8
HPEP, Hyderabad Sealing Strips for Steam Turbine   Details 0.8 0.8 0.8 0.8 0.8
HPEP, Hyderabad Sealing Strips for Steam Turbine   Details 0.8 0.8 0.8 0.8 0.8
PEM, Noida Agitators in FGD tanks   Details 20.00 10.00 10.00 10.00 10.00
PSSR, Chennai Design and supply of closed cell Borosilicate glass block lining system for FGD Chimney   Details 6 6 6 6 6
Components - Electrical & Electronics
EDN, Bangalore RESISTOR SURFACE MOUNT   Details 0.23 0.23 0.23 0.23 -
EDN, Bangalore CAPACITOR PCB MOUNT   Details 7.71 14.70 16.00 20.00 28.00
EDN, Bangalore LED SURFACE MOUNT   Details 0.26 0.26 0.26 0.26 -
EDN, Bangalore HEAT SPREADER   Details 0.28 0.28 0.28 0.28 -
EDN, Bangalore CAPACITOR SURFACE MOUNT   Details 0.46 - - - -
EDN, Bangalore DIODE   Details 0.61 1.57 1.90 2.20 3.50
EDN, Bangalore High pressure fluid Coupling for Traction application   Details 1.75 1.75 1.75 1.75 -
EDN, Bangalore Shock proof Compact USB storage   Details 0.15 0.15 0.15 0.15 -
EDN, Bangalore Semiconductor blocking device-Rectifiers   Details 0.07 0.07 0.07 0.07 -
EDN, Bangalore SWITCH ROTARY HEX   Details 0.07 0.07 0.07 0.07 -
EDN, Bangalore CABLE FIRE RETARDANT   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore INTEGRATED CIRCUIT   Details 25.9 25.9 25.9 25.9 -
EDN, Bangalore DC FAN   Details 0.12 0.12 0.12 0.12 -
EDN, Bangalore MEMORY CARD   Details 0.13 0.13 0.13 0.13 -
EDN, Bangalore RESISTOR NETWORK SURFACE MOUNT   Details 0.14 0.14 0.14 0.14 -
EDN, Bangalore FIRE RETARDANT CABLE TIE   Details 0.16 0.16 0.16 0.16 -
EDN, Bangalore TRANSFORMER SURFACE MOUNT   Details 0.19 0.19 0.19 0.19 -
EDN, Bangalore METALIC CABLE LUG   Details 0.19 0.19 0.19 0.19 -
EDN, Bangalore FIRE RETARDANT SLEEVE   Details 0.59 - - - -
EDN, Bangalore RESISTOR HIGH POWER   Details 0.60 - - - -
EDN, Bangalore CABLE HIGH VOLTAGE   Details 0.67 - - - -
EDN, Bangalore RESISTOR THROUGH HOLE   Details 0.84 - - - -
EDN, Bangalore DC-DC CONVERTER PCB MOUNT   Details 1.02 - - - -
EDN, Bangalore VARISTOR   Details 0.64 2.44 3.00 3.25 5.50
EDN, Bangalore RELAY THROUGH HOLE   Details 1.20 - - - -
EDN, Bangalore INDUCTOR   Details 1.67 - - - -
EDN, Bangalore THYRISTOR   Details 2.30 - - - -
EDN, Bangalore CONNECTOR PCB MOUNT   Details 2.86 - - - -
EDN, Bangalore FIBER OPTIC TRANSMITTER   Details 2.96 - - - -
EDN, Bangalore CAPACITOR HIGH VOLTAGE   Details 4.71 - - - -
EDN, Bangalore HEATSINK WATER COOLED   Details 6.93 - - - -
EDN, Bangalore ELECTRONIC COMMUNICATION MODULE   Details 17.00 - - - -
EDN, Bangalore IGBT   Details 5.51 5.51 5.51 5.51 -
EDN, Bangalore Din Rail Mounted Temperature Transmitters   Details 0.90 0.90 0.90 0.90 -
EDN, Bangalore Low Temperature Oxygen Analyzer   Details 0.35 0.35 0.35 0.35 -
EDN, Bangalore MERCURY ANALYZER   Details 3.00 3.00 3.00 3.00 -
EDN, Bangalore Analyzer for measuring Ambient Air & Weather parameters.   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore INTEGRATED CIRCUIT CPLD SURFACE MOUNT   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore Front silver paste for solar cell   Details 10.00 10.00 10.00 10.00 -
EDN, Bangalore PADO Licences and services   Details 10.00 10.00 10.00 10.00 -
EDN, Bangalore Traction Grade Compact Relays   Details 7.00 7.00 7.00 7.00 -
EDN, Bangalore Traction Grade Special Contactors   Details 22.00 22.00 22.00 22.00 -
EDN, Bangalore Cable accessories for Traction Application   Details 15.00 15.00 15.00 15.00 -
EDN, Bangalore FIBER OPTIC CABLE ASSEMBLY   Details 4.62 - - - -
EDN, Bangalore INTEGRATED CIRCUIT SURFACE MOUNT   Details 14.00 - - - -
EDN, Bangalore THERMISTOR   Details 0.44 - - - -
EDN, Bangalore TRANSDUCER   Details 11.95 - - - -
EDN, Bangalore Industrial panel PC 19" with keyboard, Key board tray & panel mounitng kit with Windows 10 Operating system. PROCESSOR: INTEL i5 or better, with minimum 4 cores,   Details 0.50 - - - -
EDN, Bangalore Multi solar silicon wafer   Details 25.00 25.00 25.00 25.00 -
EDN, Bangalore BACK PLANE CONNECTOR   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore FIBER OPTIC RECEIVER   Details 2.38 - - - -
EDN, Bangalore LED THROUGH HOLE   Details 0.48 - - - -
EDN, Bangalore TRANSISTOR SURFACE MOUNT   Details 0.16 0.16 0.16 0.16 -
EDN, Bangalore ELECTRONIC PROCESSOR MODULE   Details 2.73 - - - -
EDN, Bangalore Non Contact Radar type Level Transmitters   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore Coal Bunker Level Monitoring System - Strain Gauge type   Details 0.30 0.30 0.30 0.30 -
EDN, Bangalore Dual Input Temperature Transmitters   Details 2.50 2.50 2.50 2.50 -
EDN, Bangalore Hand Held Hart Communicator   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore Guided Wave Radar type Level Transmitter   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore Impact head Type Flow element   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore High Temperature Oxygen analyser   Details 0.25 0.25 0.25 0.25 -
EDN, Bangalore Positioners   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore Analyzer for measuring Emission parameters   Details 11.00 11.00 11.00 11.00 -
EDN, Bangalore Electro Pneumatic Converter   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore HF ANALYZER   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore Analyzer for measuring Emission parameters   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore Miniaturized digital display modules,48x24mm Indian Standard: Not available   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore Indicators miniaturized mosaic mountable, 48x48mm size Indian Standard: Not available   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore Mosaic items and accessories. BHEL specification: PS4152193 Indian Standard: Not available    Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore PROFIBUS COMPONENTS BHEL Specification:PS4102040, PS4102057 Indian Standard: NIL International Standard: EN61158    Details 5.10 5.10 5.10 5.10 -
EDN, Bangalore SINGLE CHANNEL SPEED MONITOR MODEL:D1553.143U1   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore PROGRAMMABLE SPEED MONITOR WITH LCD DISPLAY, POWER SUPPLY 18 TO 40V AC/DC SIGNAL INPUT:25MV TO 150V AC, OUTPUT:4 TO 20MA, ALARM RELAY OUTPUTS (PROGRAMMABLE): 2 ACCURACY: +/-0.5% TYPE: D421.52S2U1   Details 0.05 0.05 0.05 0.05 -
EDN, Bangalore Medium Voltage VFD (3.3kV, 6.6kV, 11kV) for Speed Control of motor   Details 15.00 15.00 15.00 15.00 -
EDN, Bangalore MOTORISED OFF LOAD DISCONNECTOR WITHOUT EARTHING SWITCH 75kV PEAK FOR 11 kV SYSTEM, 5000 OPERATING CYCLES   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore 24V DC/DC CONVERTER   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore AIR FLOW MONITORING UNIT FOR PROVIDING A POTENTIAL FREE CHANGE OVER CONTACT WHEN THE AIR FLOW IN THE DUCT IS LESS THAN THE SETTING.   Details 0.15 0.15 0.15 0.15 -
EDN, Bangalore Bar mounted contactors, Mechanically latched, with separate closing and tripping coils, Coil voltage : 220VDC / 110VDC, Auxiliary contacts : 6NO and 6NC, Insulation level: 5kV 50 Hz for 1 minute.   Details 5.00 5.00 5.00 5.00 -
EDN, Bangalore NON LINEAR FIELD DISCHARGE RESISTOR, RATING:2480A,900VMAX   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore Semi-Conductor Fuse, Blade type fuses to DIN standard construction. WITH TRIP INDICATOR, ADAPTOR AND MICROSWITCH HAVING ONE CHANGEOVER CONTACT. Fuse current, voltage and mounting pitch ratings change.   Details 0.40 0.40 0.40 0.40 -
EDN, Bangalore Switched mode power supply (SMPS) Input 220VDC/ 250VDC(rare) / 110VDC   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore Mark-V, Mark-VI and Mark-VIe Speedtronics Gas Turbine Control system and accessories, INPUT POWER SUPPLY 110 or 220 VAC (redundant)/ 125VDC (single)   Details 5.00 5.00 5.00 5.00 -
EDN, Bangalore Power conditioning unit   Details 50.00 50.00 50.00 50.00 -
EDN, Bangalore Slitting Machine Spare Blade Type 1/Type 2/Type 3   Details 0.08 0.08 0.08 0.08 -
EDN, Bangalore DRY CABINET   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore Spares for Weiss Technik make Environmental Chamber   Details 0.05 0.05 0.05 0.05 -
EDN, Bangalore INTEGRATED CIRCUIT AMPLIFIER SURFACE MOUNT   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore PHOTOMOS RELAY   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore THROUGH HOLE RESISTOR 100 OHM .01%   Details 0.50 0.50 0.50 0.50 -
EDN, Bangalore HEAT SPREADER   Details 0.11 0.11 0.11 0.11 -
EDN, Bangalore ELECTRONIC PROCESSOR MODULE   Details 1.75 1.75 1.75 1.75 -
EDN, Bangalore THYRISTOR   Details 0.20 0.20 0.20 0.20 -
EDN, Bangalore INTEGRATED CIRCUIT FPGA SURFACE MOUNT   Details 0.11 0.11 0.11 0.11 -
EDN, Bangalore MINIATURE PCB MOUNTED RELAY   Details 0.11 0.11 0.11 0.11 -
EDN, Bangalore DC DC CONVERTER PCB MOUNTED   Details 8.46 8.46 8.46 8.46 -
EDN, Bangalore LED SURFACE MOUNT   Details 0.05 0.05 0.05 0.05 -
EDN, Bangalore BACK PLANE CONNECTOR   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore CONNECTOR   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore RELAY   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore SWITCH PUSH BUTTON-PCB MOUNTED   Details 0.10 0.10 0.10 0.10 -
EDN, Bangalore IGBT 1200A 3300V   Details 0.35 0.35 0.35 0.35 -
EDN, Bangalore Back Aluminium paste for solar cell   Details 1.00 1.00 1.00 1.00 -
EDN, Bangalore Back silver paste for solar cell   Details 2.75 2.75 2.75 2.75 -
EDN, Bangalore Multi crystalline PV module   Details 750.00 750.00 750.00 750.00 -
EDN, Bangalore Multi crystalline solar cell   Details 55.00 55.00 55.00 55.00 -
EDN, Bangalore Communication equipment   Details 12.00 12.00 12.00 12.00 -
EDN, Bangalore Transducer for Traction application   Details 4.00 4.00 4.00 4.00 -
EDN, Bangalore Traction Grade Temp Management System   Details 1.15 1.15 1.15 1.15 -
EDN, Bangalore Traction Grade Safety Device   Details 2.67 2.67 2.67 2.67 -
EDN, Bangalore Power Capacitor for Traction application   Details 32.00 32.00 32.00 32.00 -
EDN, Bangalore Power Resistors for Traction application   Details 2.93 5.02 6.00 7.00 9.50
EDN, Bangalore E beam radiated special cable for Traction Application   Details 10.00 10.00 10.00 10.00 -
EDN, Bangalore Traction Grade High Performance Power Supplies   Details 14.00 14.00 14.00 14.00 -
EDN, Bangalore Traction grade Blower   Details 9.00 9.00 9.00 9.00 -
EDN, Bangalore Fast acting Semiconductor Fuse for Traction application   Details 1.00 1.00 1.00 1.00 -
EDN, Bangalore Traction Grade Compact MCBs with special tripping Characteristics   Details 2.60 2.60 2.60 2.60 -
EDN, Bangalore Magnetic Components for Traction application   Details 4.25 4.25 4.25 4.25 -
EDN, Bangalore PRE CHARGING RESISTOR material code TI0668085436   Details 0.36 0.36 0.36 - -
EDN, Bangalore A3 SIZE, NETWORK-READY COLOR LASER AUTO-DUPLEXING PRINTER WITH THE FOLLOWING FEATURES: SPEED: MINIMUM 26 PPM (COLOR/B&W), PRINT RESOLUTION /QUALTIY: MINIMUM 1200 X 1200 DPI, MEMORY:512MB(min), DUTY CYCLE: 50000 SHEETS (MIN) PER MONTH CONNECTIVITY: INTERNAL RJ45 UTP AND USB PORTS, LANGUAGE: PCL6 INPUT TRAY CAPACITY: 500 SHEETS (MIN), USB PRINTER CABLE TO BE PROVIDED AND ONE SET OF CATRIDGE TO BE LOADED IN PRINTER. POWER: AC 230V, 50Hz WITH INDIAN TYPE POWER CORDS. Commissioning at project site is in vendor scope 3 Year comprehensive onsite Warranty. MAKE: HP, CANON, LEXMARK, XEROX. - DA0659451620   Details 2.425 2.425 2.425 - -
EDN, Bangalore A3 SIZE, NETWORK-READY COLOR LASER AUTO-DUPLEXING PRINTER WITH THE FOLLOWING FEATURES: SPEED: MINIMUM 26 PPM (COLOR/B&W), PRINT RESOLUTION /QUALTIY: MINIMUM 1200 X 1200 DPI, MEMORY:512MB(min), DUTY CYCLE: 50000 SHEETS (MIN) PER MONTH CONNECTIVITY: INTERNAL RJ45 UTP AND USB PORTS, LANGUAGE: PCL6 INPUT TRAY CAPACITY: 500 SHEETS (MIN), USB PRINTER CABLE TO BE PROVIDED AND ONE SET OF CATRIDGE TO BE LOADED IN PRINTER. POWER: AC 230V, 50Hz WITH INDIAN TYPE POWER CORDS. Commissioning at project site is in vendor scope 3 Year comprehensive onsite Warranty. MAKE: HP, CANON, LEXMARK, XEROX. - DA0659452294   Details 2.275 2.275 2.275 - -
EDN, Bangalore IGBT gate driver with power supply As per specification PS4062372_REV01_SPECIFICATION FOR GATE DRIVER.PDF   Details 1.35 1.35 1.35 1.35 -
EDN, Bangalore Capacitor 1300 uF, 2200 V As per specification PS4062370_REV01_SPECIFICATION FOR CAPACITOR.PDF   Details 1.36 - - - -
EDN, Bangalore Resistors as per spec : Purchase specification_Resistor_PM4021   Details 0.08 0.08 0.08 - -
EDN, Bangalore IGBT of various type and ratings   Details 15.32 27.68 35.00 41.00 60.00
EDN, Bangalore Connectors of various types   Details 6.05 13.60 18.00 20.00 30.00
EDN, Bangalore Special cables of various types   Details 3.76 3.76 3.76 - -
EDN, Bangalore Analyzer for measuring Emission parameters   Details 5.00 5.00 5.00 5.00 -
EDN, Bangalore 12 Pulse Thyristor bridge based large rating SFC equipment for starting large pumps (>100MW).   Details 12.00 12.00 12.00 12.00 -
EDN, Bangalore INTEGRATED CIRCUIT ANALOG TO DIGITAL CONVERTER SURFACE MOUNT   Details 0.06 0.06 0.06 0.06 -
EDN, Bangalore DDU for Traction Application   Details 20.00 20.00 20.00 20.00 -
EDN, Bangalore Connectors as per the Spec : Purchase specification_ CONNECTORS_MOLEX_PM0604   Details 0.12 0.12 0.12 - -
EDN, Bangalore Integrated Circuits as per Spec : Purchase specification_ IC_ANALOG DEVICES_PM0800   Details 0.35 0.35 0.35 - -
EDN, Bangalore IGBT as per Spec : Purchase specification_IGBT_MITSUBISHI_PM1143   Details 11.34 11.34 11.34 - -
EDN, Bangalore Gate driver power as per spec : Purchase specification_Gate driver_Power Integration PM1933   Details 2.74 2.74 2.74 - -
EDN, Bangalore Capacitor as per spec : Purchase specification_CAPACITOR_ELECTRONICON_PM3084   Details 2.47 2.47 2.47 - -
EDN, Bangalore Heat sinks of various types and sizes   Details 1.34 1.34 1.34 - -
EDN, Bangalore Current Sensor 1000A material code TI0668110779   Details 0.638 0.638 0.638 - -
EDN, Bangalore Multifunction printer (Scanner, copier cum auto duplex printer)-A3 #Resolution: 1200 x 1200dpi (min) for printer; 600 x 600 dpi (min) for scanner #Scanning features: Scan to Folder #Scaling:25% to 400% #Memory: 2GB #Printing speed: 30ppm for A4 size, 15 ppm for A3 size #Copying feature #Auto duplex facility Paper input: Minimum: 500 Sheets INPUT TRAY POWER: AC 230V, 50Hz WITH INDIAN TYPE POWER CORDS; Commissioning at project site in vendor scope 3 Years Comprehensive On-Site Warranty. MAKE: HP/CANON/LEXMARK/XEROX - DA0659448199   Details 1.292 1.292 1.292 - -
EDN, Bangalore 4500 V, 1500 A IGBT As per PS4062377_SPECIFICATION_IGBT 4500V 1500A.PDF   Details 26.2 - - - -
EDN, Bangalore ICs of various types and functions   Details 3.20 8.41 10.00 12.00 18.00
EDN, Bangalore SMD resistors of various ratings   Details 1.34 1.34 1.34 - -
EDN, Bangalore Transformers of various type and ratings   Details 0.84 0.84 0.84 - -
EDN, Bangalore RGA PROBE Material code KA9018210459   Details 0 0 - - -
EDN, Bangalore Integrated Circuits as per Spec : Purchase specification_ IC_TEXAS_PM0802   Details 0.19 0.19 0.19 - -
EDN, Bangalore Through Hole resistors of various ratings   Details 2.71 2.71 2.71 - -
EDN, Bangalore Capacitor-Through Hole   Details 6.47 6.47 6.47 - -
EDN, Bangalore Through Hole Diodes of various types and ratings   Details 1.59 1.59 1.59 - -
EDN, Bangalore A4 printer with scanning and copy feature - network ready , Speed of minimum 16ppm (B&W) /4 ppm(colour) ,Resolution(Minimum): 600dpi, first page out time <=1 min for color, <45 sec for BW Paper input: Minimum 500 sheet tray.? MAKE : HP,LEXMARK,CANON,XEROX,EPSON. - DA0830000081   Details 0.36 0.36 0.36 - -
EDN, Bangalore Cap Matl Poly prop 8 uf, 4 pin PAC As per specification PS4062373 - DV0692391410 .pdf   Details 0.025 - - - -
EDN, Bangalore Capacitor as per spec : Purchase specification_Capacitor_Vishay_PM1401   Details 0.29 0.29 0.29 - -
EDN, Bangalore Fiber Optic Transmitter and receiver as per Spec : Purchase specification_FO COMPONENTS_BROADCOM   Details 0.44 0.44 0.44 - -
EDN, Bangalore Resistor as per spec : Purchase specification_Resistor 100k 100W_PM4019   Details 0.22 0.22 0.22 - -
EDN, Bangalore Resistors as per spec : Purchase specification_Resistor_PM4021   Details 0.08 0.08 0.08 - -
EDN, Bangalore transistors of various types and ratings   Details 0.52 0.89 0.95 1.30 1.90
EDN, Bangalore Voltg.Sensor for Traction Application. 2000VDC Material code TI0668110787   Details 1.16 1.16 1.16 - -
EDN, Bangalore Current Sensor 500A Material code TI0668110760   Details 1.914 1.914 1.914 - -
EDN, Bangalore Voltg.Sensor for Traction Appln. 1500VAC material code TI0668110795   Details 3.248 3.248 3.248 - -
EDN, Bangalore A4 printer with scanning and copy feature - network ready , Speed of minimum 16ppm (B&W) /4 ppm(colour) ,Resolution(Minimum): 600dpi, first page out time <=1 min for color, <45 sec for BW Paper input: Minimum 500 sheet tray.? MAKE : HP,LEXMARK,CANON,XEROX,EPSON. - DA0830000081   Details 0.36 0.36 0.36 - -
EDN, Bangalore Integrated Circuits as per Spec : Purchase specification_IC_FPGA_INTEL   Details 0.06 0.06 0.06 - -
EDN, Bangalore IGBT gate driver as per spec : Purchase specification_IGBT Gate driver_Inpower_ PM1925   Details 2.57 2.57 2.57 - -
EDN, Bangalore transducers of various type and rating   Details 6.02 6.02 6.02 - -
EDN, Bangalore Inductive components of various type and ratings   Details 0.31 1.06 1.30 1.50 2.25
EDN, Bangalore DC-DC converts of various ratings   Details 5.77 20.02 25.00 30.00 45.00
EDN, Bangalore Transistors of various types   Details 0.49 0.49 0.49 0.49 -
EDN, Bangalore DOTMATRIX PRINTER WITH THE FOLLOWING FEATURES: 24 Pin, Impact Dot Matrix Printer,136 column, Speed of minimum 450cps in Hi-speed draft mode (12cpi), 64Kb input buffer (minimum), Parallel port and serial/USB port. With Centronics Parallel Printer Cable, Graphic printing capability, Bi-directional black color printing. Warranty: 3 years comprehensive on site - DA0659446235   Details 0.02 - - - -
EDN, Bangalore capacitors of various type and ratings   Details 1.36 1.36 1.36 - -
EDN, Bangalore LEDs of various types and sizes   Details 0.23 0.40 0.50 0.58 0.90
EDN, Bangalore CURRENT TRANSDUCER 2000A matrerial code TI0693077786   Details 2.89 2.89 2.89 - -
EDN, Bangalore CURRENT TRANSDUCER 2000A matrerial code TI0693077786   Details 2.89 2.89 2.89 - -
EDN, Bangalore DOTMATRIX PRINTER WITH THE FOLLOWING FEATURES: 24 Pin, Impact Dot Matrix Printer,136 column, Speed of minimum 450cps in Hi-speed draft mode (12cpi), 64Kb input buffer (minimum), Parallel port and serial/USB port. With Centronics Parallel Printer Cable, Graphic printing capability, Bi-directional black color printing. Warranty: 3 years comprehensive on site - DA0659446235   Details 0.02 - - - -
EDN, Bangalore A3 SIZE, NETWORK-READY COLOR LASER AUTO-DUPLEXING PRINTER WITH THE FOLLOWING FEATURES: SPEED: MINIMUM 26 PPM (COLOR/B&W), PRINT RESOLUTION /QUALTIY: MINIMUM 1200 X 1200 DPI, MEMORY:512MB(min), DUTY CYCLE: 50000 SHEETS (MIN) PER MONTH CONNECTIVITY: INTERNAL RJ45 UTP AND USB PORTS, LANGUAGE: PCL6 INPUT TRAY CAPACITY: 500 SHEETS (MIN), USB PRINTER CABLE TO BE PROVIDED AND ONE SET OF CATRIDGE TO BE LOADED IN PRINTER. POWER: AC 230V, 50Hz WITH INDIAN TYPE POWER CORDS. Commissioning at project site is in vendor scope 3 Year comprehensive onsite Warranty. MAKE: HP, CANON, LEXMARK, XEROX. - DA0659452294   Details 2.275 2.275 2.275 - -
EDN, Bangalore Thyristors of various types and rating   Details 3 3 3 - -
EDN, Bangalore Switches of various types and ratings   Details 0.25 0.47 0.65 0.70 1.00
EDN, Bangalore Fibre Optics components   Details 0.80 0.84 1.00 1.10 1.75
EDN, Bangalore Relays of various types,sizes and ratings   Details 1.91 3.03 3.90 4.50 5.60
EDN, Bangalore Electronics modules for various functions   Details 5.99 9.58 11.60 14.00 20.00
EDN, Bangalore Fuses of various types and ratings   Details 0.57 0.57 0.57 - -
HEEP, Haridwar Slot Wedges / Wedge Profile Bars   Details 9.40 9.40 9.40 10.00 12.00
HEEP, Haridwar TERMINAL BUSHING   Details 14.40 7.20 5.40 4.30 5.00
HEEP, Haridwar Differential Pressure Regulating Valve Type-A (Size NB 32   Details 1.14 0.98 0.98 1.5 1.5
HEEP, Haridwar Solenoid Valve NB40   Details .30 .20 0.20 0.40 0.40
HEEP, Haridwar Multi Contact Socket, Multi Contact Band & Spring Ring   Details 0.47 0.47 .47 0.60 0.60
HEEP, Haridwar Copper Strip Hollow   Details 5.0 4.2 4.2 5.0 5.0
HEEP, Haridwar DURALUMIN PROFILE BAR   Details 0.07 0.07 0.07 0.15 0.15
HEEP, Haridwar Support Ring (TS), Support Ring (ES), Seal Ring (in two halves), Outer seal Ring (in 3 Pars)   Details 6.72 4.00 4.00 4.5 5.0
HEEP, Haridwar Permanent Magnet   Details .38 .38 .38 0.50 0.50
HEEP, Haridwar Vacuum Pump (Rotary Vane Type)   Details .36 .36 .36 0.50 0.50
HEEP, Haridwar Hollow Copper Conductors & Filler Profiles   Details 7.19 7.19 7.19 9.0 9.00
HEEP, Haridwar Damper Wedges   Details .28 .28 0.28 0.50 0.35
HEEP, Haridwar EQUALISING VALVES   Details .96 .72 .72 1.00 1.00
HEEP, Haridwar FIELD LEAD CORE BAR   Details .93 .93 .93 1.20 1.20
HEEP, Haridwar Rectangular Stainless Steel Hollow Tubes   Details 7.55 7.55 7.55 9.00 9.00
HEEP, Haridwar Copper Seamless Drawn Tubes (With Controlled Oxygen Content)   Details 0.19 0.19 0.19 0.25 0.30
HEEP, Haridwar Pressure Regulator   Details .30 .20 .20 0.50 0.45
HEP, Bhopal Free Running impeller (Cooling fan)   Details 0.13 0.13 0.13 0.13 0.13
HEP, Bhopal Relays   Details 0.55 0.55 0.55 .55 0.55
HEP, Bhopal VBLG load ring   Details 0.28 0.28 0.28 0.28 0.28
HEP, Bhopal Bi-Axially Oriented Poly Propylene Film (BOPP Film) For Capacitor   Details 26 30 30 30 30
HEP, Bhopal Surge arrester (Plug in Type) for 36kV GIS,36kV Gas Insulated Switchgear. As per Tech Spec. SG12505 (Copy attached)   Details 1 1.13 1.13 1.13 1.13
HEP, Bhopal Armature Reversing Contactor   Details 0.06 0.06 0.06 0.06 0.06
HEP, Bhopal Vibration Measurement Probes & Transmitters   Details 0.80 0.80 0.80 0.80 0.80
HEP, Bhopal Oil to SF6 Resin Impregnated paper (RIP) bushing Voltage- 800 kV, 420 kV & 245 kV Current rating - 2500A, 2000A, 1250 A BIL level (kV/kVp): 970/2100 (For 800 kV), 695/ 1425 (For 420 kV), 505/ 1050 (For 245 kV). Other requirements as per IEC:60137   Details 8.00 8.0 8 8 8
HEP, Bhopal Partial Discharge Couplers and Transmitters   Details 0.35 .35 .35 .35 0.35
HEP, Bhopal Speed Measuring device - Pulse Encoder/ Tacho Generator   Details 0.25 0.25 0.25 .25 0.25
HEP, Bhopal Aluminium Foil- High Purity For Capacitor (less than 10 micron thick)   Details 8.4 2.5 2.5 2.5 2.5
HEP, Bhopal Item No.001 : Water Cooled Heat Sink with Rth less than 2 0C/kW, Pressure drop less than 800 mbar at 16 LPM, with NTC mounted, suitable for IGBT package of 130x140 mm. Item No.002 : Water Cooled Heat Sink with Rth less than 3 0C/kW, Pressure drop less than 800 mbar at 16 LPM, suitable for IGBT package of 150x166 mm.   Details 1.20 1.20 1.20 1.20 1.20
HEP, Bhopal Partial Discharge Monitoring Equipments   Details 2.00 2 2 2 2
HEP, Bhopal Metal film capacitors of traction duty with following ratings: Item No.001: 4.5mF, 2.2KV DC Item No.002: 2.25mF, 2.2KV DC Item No.003: 4.5mF, 150V DC   Details 2.46 2.46 2.46 2.46 2.46
HEP, Bhopal 1. MASTER GATE DRIVER WITH OPTICAL INTERFACE WITH ST CONNECTION, SUITABLE FOR IGBT MODULES 1200A /3.3KV, Package 130x140 2. SLAVE GATE DRIVER WITH OPTICAL INTERFACE WITH ST CONNECTION, SUITABLE FOR IGBT MODULES 1200A /3.3KV, Package 130x140 AND COMPATIBLE WITH Item No.001    Details 1.38 1.38 1.38 1.38 1.38
HEP, Bhopal IGBT 1200A /3.3KV, Package 130x140 Dual IGBT 1400A/1.2KV , Package 150x166   Details 3.06 3.06 3.06 3.06 3.06
HEP, Bhopal Metrosil assembly unit   Details 0.05 0.05 0.05 0.05 0.05
HEP, Bhopal Bushings   Details 0.20 0.20 0.20 .20 0.20
HEP, Bhopal DC Field Circuit Breaker 630A for Static Excitation Equipment for 11kV, 4.7MW Synchronous Motor for Pattisam LIS project    Details 0.07 0.07 0.07 0.07 0.07
HEP, Bhopal 8000A, 900V DC HIGH SPEED DC CIRCUIT BREAKER, MAKE : SECHERON, DESIGNATION CODE : UR80-81    Details 1.00 1 1 1 1
HEP, Bhopal Assignment Contactor   Details 0.20 0.20 0.20 0.20 0.20
HEP, Bhopal Single / MultiHeavy Duty Pin Plug   Details 0.75 0.75 0.75 0.75 0.75
HEP, Bhopal AVR Controller for Excitation control panel   Details 0.15 0.15 0.15 0.15 0.15
HEP, Bhopal On load Tap Changer (OLTC) for higher amperage   Details 6.86 6.86 6.86 6.86 7.00
HEP, Bhopal Item No.001 : Laminated Bus Bar for IGBT connections of Booster and FQC, Rating : AC: 1450A, 1350V, DC : 900A, 1800V as per BHEL Spec PS 407401 Item No.002 : Laminated Bus Bar for Capacitor Interconnections of Booster and FQC, Rating : AC: 1450A, 1350V, DC : 900A, 1800V as per BHEL Spec PS 407401 Item No.003 : Laminated Bus Bar for Buck Chopper Rating : DC : 900A, 100V as per BHEL Spec PS 407401    Details 1.58 1.58 1.58 1.58 1.58
HEP, Bhopal Metrosil assembly unit for Static Excitation Equipment for 11kV, 4.7MW Synchronous Motor for Pattisam LIS project   Details 0.05 0.05 0.05 0.05 0.05
HEP, Bhopal Elastimold   Details 216 216 216 216 216
HEP, Bhopal Current and voltage sensors   Details 0.92 0.92 0.92 .92 0.92
HERP, Varanasi 3-PHASE SQUIRREL CAGE INDUCTION MOTOR   Details 0.76 0.76 0.76 0.76 0.76
HERP, Varanasi Automatic Power Control System Receiver   Details 2.72 2.30 2.30 2.30 2.50
HERP, Varanasi Double row spherical roller bearing type   Details 0.53 0.25 0.15 0.15 0.15
HPBP, Trichy QNX Board Support Packages (BSPs) Run Time License   Details 0.16 0.16 0.16 0.16 0.16
HPBP, Trichy Crystal Oscillator   Details 0.25 0.25 0.25 0.25 0.25
HPBP, Trichy Battery PCB Mounted   Details 0.07 0.07 0.07 0.07 0.10
HPBP, Trichy Potentiometer PCB Mounted   Details 0.82 1.13 1.40 1.70 2.50
HPBP, Trichy Solid State Memory Devices   Details 0.06 0.06 0.06 0.06 0.08
HPEP, Hyderabad Pressure compensator   Details 1.2 1.2 1.2 1.2 1.2
HPEP, Hyderabad Pressure compensator   Details 1.2 1.2 1.2 1.2 1.2
HPEP, Hyderabad Stainless Steel Caulking Wires for Steam Turbines   Details 1.28 0.8 0.8 0.8 1.00
HPEP, Hyderabad Stainless Steel Caulking Wires for Steam Turbines   Details 1.28 0.8 0.8 0.8 1.00
HPEP, Hyderabad BEARING RTD Resistance Temperature Detector PT 100   Details 1.8 1.8 1.8 2.0 2.0
HPEP, Hyderabad BEARING RTD Resistance Temperature Detector PT 100   Details 1.8 1.8 1.8 2.0 2.0
PEM, Noida Generator circuit breaker (GCB)   Details 10.00 7.5 0 - -
Consumables for Foundry applications
CFFP, Haridwar Nickel Specn.FF05061R02 Re.0   Details 29 29 29 29 29
CFFP, Haridwar Chromite Sand Specification No AA53627 Rev.04   Details 5.30 5.00 5.00 5.00 5.00
CFFP, Haridwar Cobalt Alloy # 6 Ingots Specn.:FF06031 R02   Details 1.40 1.40 1.40 1.40 1.40
CFFP, Haridwar Metallic Manganse (Flakes)/Manganse Metal   Details 0.53 0.50 0.50 0.50 0.50
CFFP, Haridwar Insulating Tiles Diff.sizes   Details 2.36 2.36 2.36 2.36 2.36
CFFP, Haridwar Flourspar Lumps Specn: FF05015   Details 0.39 0.39 0.39 0.39 0.39
CFFP, Haridwar Super Alloy Grade HP Valve casing   Details 4.00 4.00 4.00 4.00 4.00
CFFP, Haridwar Nitrided Low Carbon Ferro-Chrome Specn.: FF05069   Details 1.01 1.00 1.00 1.00 1.00
Insulating Materials
HEEP, Haridwar Conductive Fleece Tape   Details .10 .08 0.08 0.35 0.50
HEEP, Haridwar Rotor Flux Monitoring System   Details 1 .9 .9 1.0 1.0
HEEP, Haridwar Epoxy Resin Treated Nomex Paper (All widths)   Details .25 .24 .24 0.30 0.30
HEEP, Haridwar Resin and Curing Agent   Details .20 .18 .18 0.25 0.25
HEEP, Haridwar Magnetic Steel Varnish   Details 3 3 3 3 5
HEEP, Haridwar Conducting Varnish Low Ohmic Grade   Details .18 .16 0.16 0.20 0.20
HEEP, Haridwar Conductive Polyester Fleece   Details .35 .30 0.30 0.40 0.50
HEEP, Haridwar Slot Side Ripple Spring   Details .45 .40 .40 1 1
HEEP, Haridwar Slot Top Ripple Spring   Details .35 .35 .35 0.40 0.50
HEEP, Haridwar COCOONISING ITEMS (ISOCOON 222 SILVER UV, ISOBOND 950 AND ALUMINIUM TAPE)   Details .85 .80 .80 0.95 1.00
HEEP, Haridwar Insulating Red Enamel Damcoat 2404   Details 0.10 0.20 0.10 0.10 0.10
HEEP, Haridwar Conductive Hard Fleece Sheet   Details .14 .12 0.12 0.20 0.25
HEEP, Haridwar Semi Conducting Varnish   Details .08 .08 0.08 0.10 0.10
HEP, Bhopal RTV (SILICONE RUBBER ELASTOMER RT 622 A/B OR EQUIVALENT) for AC machines,   Details 1.73 1.73 1.73 1.73 1.85
HEP, Bhopal Polyester Fibre fleece Tape   Details 0.34 0.34 0.34 0.34 0.34
HEP, Bhopal RTV (SILICONE RUBBER ELASTOMER RT 622 A/B OR EQUIVALENT) for AC machines,   Details 12.94 12.94 12.94 12.94 12.94
HEP, Bhopal Kraft Insulating Paper   Details 0.25 0.25 0.25 .25 0.25
HEP, Bhopal Capacitor Tissue Paper   Details 6 1.75 1.75 1.75 1.75
HEP, Bhopal RESIN & HARDNER (PMDAEM01#63)   Details 2.96 2.96 2.96 2.96 3.00
HEP, Bhopal Catalyst/ Additive – HILFSSTOFF 38 HZN 451560P   Details 2.27 2.27 2.27 2.27 2.27
HEP, Bhopal STRESS GRADING PAINT (SEMI CONDUCTING VARNISH/SIB- 8001).   Details 0.79 0.79 0.79 0.79 0.79
HEP, Bhopal POLYAMIDE (CALENDER PAPER) NOMEX #1)0.18 x 914 mm ,#2)0.25 x 914 mm ,#3) 0.51 x 914 mm and #4) 0.76 *914 mm    Details 0.43 0.43 0.43 0.43 0.43
HEP, Bhopal POLYIMIDE (KAPTON/APICAL) FILM/ TAPE   Details 0.29 0.29 0.29 0.29 0.29
HEP, Bhopal 0.125 x 510 MM POLYIMIDE FOIL PI-FO1 (KAPTON)   Details 2.09 2.09 2.09 2.09 2.09
HEP, Bhopal GM LOCO MATERIAL(SILICON RUBBER FIBRE GLASS TAPE & WRAPPER) AS PER SPEC TM00285   Details 0.18 0.18 0.18 0.18 0.18
HEP, Bhopal Press board to standard IEC 60641-3-1 and IEC60763   Details 8 8 8 8 8
HEP, Bhopal Silicon Rubber Elastomer RT 622 A/B or Equivalent   Details 1.20 1.20 1.20 1.20 1.20
HEP, Bhopal Silicon Impregnating Resin (SILRES H62C)   Details 13.43 12.30 12.30 12.30 12.30
HEP, Bhopal Tangential beech wood Ring to standard IEC:61061 for Electrical purposes   Details 2.8 2.8 2.8 2.8 2.8
HEP, Bhopal Synthetic Capacitor Oil   Details 2.2 2.2 2.2 2.2 2.2
HEP, Bhopal POLYPROPYLENE FILM FOAMED TYPE   Details 0.3 0.3 0.3 0.3 0.3
HEP, Bhopal HILFSSTOFF 38 HZN 451560P   Details 4.05 4.05 4.05 4.05 4.05
HERP, Varanasi Polybutadine Varnish alongwith its inhibitor & Diluent   Details 1 0.75 0.75 0.75 1.00
HPVP, Vizag INSULATION MATERIAL( TOTAL 06 ITEMS IN ONE SET )   Details 0.36 0.36 0.36 0.36 0.36
SBD, Bengaluru Nitride Bonded Silicon Carbide (SiSiC) Beam   Details 0.35 0.36 0.37 0.40 0.40
TP, Jhansi SILICONE OIL AS PER JS27197 AND IEC 60836   Details 8.64 7.65 8.10 - -
Raw Material Special / Alloy / Electric Steel
HEEP, Haridwar 800 MW Slot Wedges   Details 10 12 12 12 12
HPBP, Trichy Seamless Alloy Steel Pipes (Grade P91 & P92)   Details 1500 1500 1800 1500 1800
Raw Material – Special / Alloy / Electric Steel
EDN, Bangalore LNCA (GRADE: NCA 7051)   Details 0.47 0.51 - - -
HEEP, Haridwar BOILER QUALITY PLATES & PRESSURE VESSEL PLATES (thickness more than 150 mm)   Details 3.00 3.00 3.00 3.00 3.20
HEEP, Haridwar AUSTENITIC STAINLESS STEEL PLATES   Details 0.40 0.30 .30 0.50 0.50
HEP, Bhopal 1. NU1014 M ECMR/HC5C4S0 (SKF nomenclature) or equivalent of other Bearing manufacturer 2. 6214 M/HC5C4S0 (SKF nomenclature) or equivalent of other Bearing manufacturer   Details 5.1840 5.1840 6 6 6
HEP, Bhopal "1. NU1014 M ECMR/HC5C4S0 (SKF nomenclature) or equivalent of other Bearing manufacturer 2. 6214 M/HC5C4S0 (SKF nomenclature) or equivalent of other Bearing manufacturer "   Details 5.1840 5.1840 - - -
HPBP, Trichy Seamless Alloy Steel Tubes (Grade T23 & T92)   Details 200 200 240 200 250
HPBP, Trichy Seamless Carbon Steel Pipes (Grade B & C)   Details 450 450 540 450 540
HPBP, Trichy Seamless Alloy Steel Pipes (Grade P12 & P22)   Details 200 200 240 200 250
HPVP, Vizag 0.0762mm SS347 Foil   Details 0.54 0.378 0.54 0.54 0.54
SBD, Bengaluru Multi-Crystalline - Diamond Wire Saw - Silicone Wafers 156.75 mm or 158.75 mm (Technical Specifications PS-439-407 Rev 01, PS-439-411 Rev 01, PS-439-422 Rev 00 & PS-439-423 Rev 00)   Details 94.27 98.98 103.21 100.00 100.00
SBD, Bengaluru Calcined Alumina as per Specification No. : Issue : 05 Sec :47.0 Rev 01 Dated Jan 2013   Details 3.17 3.42 3.68 3.75 3.75
SBD, Bengaluru Multi/Mono Crystalline Solar Cell (Technical Specification PS:901:05:0020 Rev 03)   Details 168.47 176.89 185.95 200.00 200.00
SBD, Bengaluru Back Silver Paste (Technical Specification PS:439:355 Rev 03)   Details 3.34 3.51 3.70 4.00 4.00
SBD, Bengaluru Front Silver Paste (Technical Specification PS:439:431 Rev 00)   Details 22.32 23.44 24.68 25.00 25.00
SBD, Bengaluru Clay Powder as per BHEL Specification No.: Issue:06 SCR-D-RM-007 Rev 01 June 2022)   Details 0.57 0.52 0.74 0.69 0.75
SBD, Bengaluru Back Aluminium Paste (Technical Specification PS:439:356 Rev 02)   Details 1.76 1.85 1.95 2.00 2.00
SBD, Bengaluru Liquid Silicone Rubber (LSR) as per BHEL Specification No.: EL-CI-LSR-02 Rev 00 Dated 02/07/2013   Details 0.98 1.02 1.20 1.20 1.20
SBD, Bengaluru Titanium DiOxide ( TiO₂) Powder   Details 33.49 34.95 36.63 40.00 35.00
Raw Material – Special / Alloy / Electric Steel
BAP, Ranipet Titanium Sheet (2X1000X6000)   Details 1.00 1.00 1.00 1.00 1.00
BAP, Ranipet Plate S-TEN-1 or Equivalent - 9mm Thick   Details 6.00 6.00 6.00 6.00 6.00
BAP, Ranipet CR Sheet 2mm to Spec ASTM B575 UNS N10276, Plates 5mm to Spec ASTM B575 UNS N06059, Cold Drawn Coiled Sheet (0.1mm Thick) to Spec ASTM B575 UNS N10276   Details 15.40 15.40 15.40 15.40 15.40
HEEP, Haridwar CORLD ROLLED NON GRAIN ORIENTED (CRNGO) SHEET STEEL   Details 39.55 39.55 39.55 50.00 50.00
HEP, Bhopal CRGO Coils Gr 23DR, 27DR   Details 65.00 65 65 65 65
HEP, Bhopal CRNGO 50 Gr. 270   Details 50.00 50 50 50 80
HPEP, Hyderabad Turbine Blade Flats   Details 1.50 1.50 1.50 2.00 2.00
HPEP, Hyderabad Turbine Blade Flats   Details 1.50 1.50 1.50 2.00 2.00
SBD, Bengaluru English Hymod Blue as per BHEL Specification - Issue-05 ,Section 42.0 , Rev 00 Dated June 2009   Details 1.80 2.08 2.4 2.77 2.5
SBD, Bengaluru HTV Silicone Compound as per BHEL Specification No. EL-CI-SC-01 Rev 02 Dated 02.04.2015   Details 28.09 29.31 31.20 31.20 31.20
SBD, Bengaluru Japan Ball Clay as per BHEL Specification - Issue-05 ,Section 19.0 , Rev 00 Dated June 2009   Details 0.23 0.27 0.31 0.36 0.36
SBD, Bengaluru Alumina 96 (High Grade) as per BHEL Specification No. NP-D-RM-02 Rev 00 Dated October 2021   Details 0.62 0.64 0.67 0.67 0.67
Special Grade Batteries
EDN, Bangalore Fibre Plated Ni-Cd Battery   Details 15.00 15.00 15.00 15.00 15.00
EDN, Bangalore PEM, Noida Lead Acid Plante Battery   Details 20.00 20.00 20.00 20.00 20.00
Specialized Processing of Raw Material
BAP, Ranipet Cladded Plate (Carbon Steel Plate 7mm + Titanium Sheet 2mm ) x 2500 x 6000 mm   Details 22.50 22.50 22.50 22.50 22.50
BAP, Ranipet Cladded Plate (Carbon Steel Plate 7/8/12mm + C276 2mm ) x 2200 x 6000 mm   Details 80.00 80.00 80.00 80.00 80
HEEP, Haridwar Stainless Steel Strip   Details 2.00 2.20 0.82 0.75 0.66
HEEP, Haridwar Cold Rolled Steel Strip   Details 0.12 0.12 0.12 0.20 0.20
HERP, Varanasi Heat Shrinkable Sleeve (Polyester)   Details 0.45 0.45 0.45 0.45 0.45
HPEP, Hyderabad Stainless Steel Profile Bars for Steam Turbine Blades   Details 2.19 2.19 2.19 2.50 2.50
HPEP, Hyderabad Stainless Steel Profile Bars for Steam Turbine Blades   Details 2.19 2.19 2.19 2.50 2.50
HPVP, Vizag Aluminium Fin Foil   Details 0.312 0.312 0.312 0.312 0.312
HPVP, Vizag 0.254mm X 150mm Width SS347 Coil   Details 0.5 0.5 0.5 0.5 0.5
HPVP, Vizag Cladded Plate (Carbon Steel Plate 7mm + BQ plates ) x 2500 x 6000 mm   Details 10.00 10.00 10.00 10.00 10
HPVP, Vizag 0.762mm SS347 Foil   Details 0.54 0.378 0.5 0.5 0.5
HPVP, Vizag 0.254mm X 130mm Width SS347 Coil   Details 0.5 0.5 0.5 0.5 0.5
Systems/ Packages
EDN, Bangalore Steam and Water Analysis System (SWAS) Analysers   Details 15.00 15.00 15.00 15.00 -
EDN, Bangalore Calibration equipment for field Vibration Sensors & Vibration Monitoring System.   Details 0.75 0.75 0.75 0.75 -
EDN, Bangalore Vibration Monitoring System (VMS)   Details 21.00 21.00 21.00 21.00 -
EDN, Bangalore ValmetDNA Control System and accessories, Compatible Standards: 1. Standards Quality system ISO 9001(2000) Environmental system ISO 14001(1996) Communication IEEE802.3 (Ethernet) IEEE802.4 (Token bus) Color recommendations are based on SFS-EN 60073. Environmetal requirements for equipment (SFS-EN) IEC 60721-3-3K2 (SFS-EN) IEC 60721-3-3B1 (SFS-EN) IEC 60721-3-3C1/2 (SFS-EN) IEC 60721-3-3S1/2 (SFS-EN) IEC 60721-3-3M1/2 IP20, IP54/55 System power supply IEC 60439-1, SFS-EN 60439-1 (2000) IEC 60204-1, SFS-EN 60204-1 (1998,2000) Power supply to field cabinets Category 3 of the IEC 60644, SFS-EN 60644 (1993) EMC Electromagnetic compatibility (EMC): Generic standards: 25.09.2013 Page 1 (2) SFS-EN 61000-6-3 Emission standard for residential, commercial and light-industry environments SFS-EN 61000-6-4 SFS-EN 61000-6-1 SFS-EN 61000-6-2 De facto standards: TCP/lP, X Windows System   Details 9.00 9.00 9.00 9.00 -
EDN, Bangalore Coal Bunker Level Monitoring System - 3D Scanner type   Details 2.50 2.50 2.50 2.50 -
EDN, Bangalore Steam Turbine Vibration monitoring, diagnostic and analysis system   Details 6.00 6.00 6.00 6.00 -
EDN, Bangalore Coal Bunker Level Monitoring System - Radar / Ultrasonic type   Details 0.20 0.20 0.20 0.20 -
HEEP, Haridwar Fiber optics Generator End winding vibration monitoring system.   Details 3.00 3.00 3.00 3.00 3.00
HEP, Bhopal Pressurization Control System   Details 1.60 1.60 1.60 1.60 1.60
HPBP, Trichy Boiler Circulation Water Pump also referred as Boiler Water Circulation (BWC) Pump is used to maintain a minimum flow through the economizer and evaporator of a supercritical boiler.   Details 30 30 36 30 36
HPBP, Trichy Hydraulic Snubbers   Details 6 6 7.2 5.0 5.0
HPBP, Trichy Furnace Maintenance Platform   Details 3.5 3.5 4.2 3.5 4.5
HPBP, Trichy Regulating duty electrical actuator for fan blade pitch control   Details 8 8 9.6 13 9.6
HPBP, Trichy Intrascope   Details 1.5 1.5 1.8 1.50 2.0
HPEP, Hyderabad Speed Increasing Gear Box for Compressors   Details 0.75 0.75 0.75 0.90 0.90
HPEP, Hyderabad 125 MT Work Over Rig Carrier Package   Details 8.75 0 0 0 0
HPEP, Hyderabad Speed Increasing Gear Box for Compressors   Details 0.75 0.75 0.75 0.90 0.90
HPEP, Hyderabad Seal Gas Booster for Compressor Projects   Details 2.7 2.7 2.7 3.0 3.0
HPEP, Hyderabad Seal Gas Booster for Compressor Projects   Details 2.7 2.7 2.7 3.0 3.0
HPEP, Hyderabad Gear Box > 15 MW for Steam Turbines   Details 1.00 1.00 1.00 1.10 1.25
HPEP, Hyderabad Gear Box > 15 MW for Steam Turbines   Details 1.00 1.00 1.00 1.10 1.25
HPEP, Hyderabad 125 MT Work Over Rig Carrier Package   Details 8.75 0 0 0 0
HPEP, Hyderabad Twin Ram EDM Die Sinking Machine   Details 0 0 0 9.53 0
HPEP, Hyderabad Twin Ram EDM Die Sinking Machine   Details 0 0 0 9.53 0
PEM, Noida GYPSUM DEWATERING SYSTEM (GDS) COMPRISING OF VACUUM BELT FILTER (VBF), HYDROCYCLONES & ASSOCIATED ITEMS)   Details 60.00 42 20 20 -
PEM, Noida VIS OF TG FOUNDATION   Details 2.00 2.00 2.00 2.00 -
PEM, Noida VIS OF BFP, FAN & MILL FOUNDATION   Details 0.50 0.50 0.50 0.50 -
PESD, Hyderabad 8 MW Gas Engines   Details 100.00 100.00 100.00 100.00 -
Testing Facilities
HEP, Bhopal TYPE TESTING OF 420kV, 50kA GIS   Details 1.50 1.50 1.50 1.50 1.50
Welding consumables of special grade
CFFP, Haridwar Tungsten Grade Welding Electrode   Details 1.20 1.20 1.20 1.20 1.20
HEEP, Haridwar Brazing Alloy / Rod, Soldering Wire & Brazing Foil and Flux   Details 1.37 1.37 1.37 1.50 1.75
HEEP, Haridwar GMAW welding filler wire for supercritical projects.   Details .65 .50 .50 .50 0.50
HEP, Bhopal NIMO FCAW Wire   Details 1.44 1.44 1.44 1.44 1.44
